GT-DJ330 Vertical Dispensing Machine

GT-DJ330 Vertical Dispensing Machine

OKATA is capable of manufacturing and providing GT-DJ330 vertical dispensing machine, whose maximum movement range is 2000mm*360mm*100mm. Featuring high efficiency, the auto glue dispensing system can process large batch products at a time.

Compatible glues and adhesives

The vertical dispensing machine is compatible with solder mask, COB black glue, red glue, solder paste, UV adhesive, SILICON, EPOXY, silver glue, AB glue, conducting resin, thermal grease solder paste, instant glue and other kinds of fluid dispensing.

Applications

LED lamp holder sealing
Semi-conductor packaging
PCB electronic components fixation and protection
Loudspeaker adhesive dispensing
LCD glass plate packaging
Chip bonding
Mobile phone dispensing
Battery box dispensing and bonding
Hardware parts coating and bonding
Automobile components coating
Quantitative gas or liquid coating

Features

Large stroke: 2000mm*360mm*100mm. Capability of processing large batch products at a time.
Functions of drawing points, lines, rectangles, arcs and circles, continuous interpolation of irregular curves and three-axis linkage.
Overall correction, area correction and area array functions available. Simple machine operations.
Windows XP Chinese operation interface, easy to learn and operate. 80G hard disk super storage and memory capacity.
According to customer’s requirements, station locating pin, dispensing syringe fixture and temperature regulating device can be added.
Double head adjustable syringe fixture available to greatly increase dispensing efficiency.
300cc large syringe or glue storage pressure barrel available to save glue replacement time.

Parameters

Model	GT100/GT200
Work platform (upon request)	300mm200mm60mm/ 480mm220mm60mm
Drive motor	stepper motor/servo motor(optional)
Drive method	imported timing belt/high precision ball screw (optional)
Host computer	PC + motion control card
Display	14″ LCD
Operation software	Microcomputer control
Position precision	0.01mm
Repetition precision	+/-0.005mm
Input power	AC220V,50HZ

Applications

Semi-conductor packaging
PCB electronic components fixation and protection
Loudspeaker adhesive dispensing
LCD glass plate packaging
Chip bonding
Mobile phone dispensing
Battery box dispensing and bonding
Hardware parts coating and bonding
Automobile components coating
Quantitative gas or liquid coating
