GT-LS331T Single Platform Screw Driving Machine


Description

The GT-LS331T single platform screw driving machine features a single Y axis platform, which is mainly used for screw locking products whose dimensions smaller than 400*500mm. Custom screw driving systems are available for larger products. Automatic conveyor belts can be added to create a fully automated process.

Advantages
  • Compound movement of X, Y, Z and R axis meets the 3D screw driving requirements.
  • Two types of automatic screw feeding systems: air output or air input type.
  • Precision motor control delivers higher precision and stability.
  • 5-inch true color teaching pendant is easy to learn and operate.
Parameters
Model No. GT-LS331T GT-LS431T GT-LS531T GT-LS541T
Outer dimensions L520*W600*H720mm L620*W680*H720mm L700*W680*H720mm L720*W680*H720mm
Movement range X axis 300mm 400mm 500mm 500mm
Y axis 300mm 300mm 300mm 400mm
Z axis 100mm 100mm 100mm 100mm
Work platform Single platform
Speed range 0.1~800mm/sec
Position precision ±0.02mm
Repetition precision ±0.02mm
Work load 8kg
Drive method Precision stepper motor + timing belt
Control system Handle controller
Speed control undefinedundefinedAutomatic speed decrease and increase
undefinedEfficiency of locking screws 0.7-2s/PCS
Electric screwdriver Upon request
Screw feeding Air input/air output (optional)
Screw feeding speed 60 screws/min
Compatible screw diameter Air output type: M2-M5mm Air input type: M1-M5mm
Compatible screw types Round head/ flat head/ counter sunk
Compatible screw length Air output type: 5-25mm Air input type: 2-25mm
Compatible torque 0.1~25kgf.cm
Program storage capacity ≥100 programs
Communication port USB
Operating temp. 0℃~40℃
Operating humidity 20~90%
Air supply 0.4~0.6Mpa
Power supply 220V.50HZ
Weight 30kg 40kg 45kg 50kg
Automatic detections Screw slippage detection Yes
undefinedScrew missing detection Yes
Screw height detection Yes

Note: above are the parameters of a standard single platform screw driving machine. A larger movement range is customizable upon your request.

Applications
  • Communication industry: mouse, smart phone, battery, tuner of different wavebands.
  • LED industry: LED modules, LED panel, LED chip, LED ball lamp and etc.
  • Household appliance industry: air conditioner remote control, TV enclosure, radio, sound and etc.
  • Automobile industry: vehicle-mounted remote control, car gear shift knob, vehicle-mounted DVD player, etc.
  • Toy industry: toy gun, toy handle and etc.

Professional non-standard custom-tailored solutions are provided by OKATA to meet screw locking requirements of hardware, plastic and wood products.
Guangdong Okata Intelligent Technology Co.,Ltd. has been playing its part in the movement of automation development since our founding in 2005. Our concentration is on the R&D and production of high-precision automation equipment for unmanned production workshops. Our core products include automated soldering machines, automatic screw driving machines, and automatic dispensers. These pieces of advanced equipment are utilized by producers of electronics, electrical appliances, toys, communications equipment, cars, and other industries. We provide systematic automated solutions and comprehensive equipment that has made us a well-known enterprise in the industry.
